LC APC Single Mode Connector LC-APC-SM(Step type)
LC APC Single Mode Connector LC-APC-SM(Step type)
Model: LC-APC-SM(Step type)
Place of origin: Shenzhen
Key Features:
1, Low insertion loss and back reflection loss;
2, Ferrule end surface predomed;
3, Precision anti-rotation key and corrosion resistant body;
4, UL-rated plastic housing;
5, Boots in a variety of colors;
6, Telcordia style boots;
7, Free-floating ceramic ferrule.
Parameters of LC series:
|
Paramter |
Singlemode(PC) |
Singlemode(APC) |
Multimode (PC) |
|
Insertion loss |
≤0.2 dB |
≤0.2dB |
≤0.2dB |
|
Return Loss |
≥50 dB |
≥65 dB |
≥35 dB |
|
Operating Temperature |
-40°C to +80°C |
-40°C to +80°C |
-40°C to +80°C |
Availability:
The connector can be supplied as a pre-assembled one-piece connector or as connector kits.
Clips are available for duplex connectors.
Housing kits without ferrule are available.
Applications:
1, CATV
2, Active device termination
3, Telecommunicationnetworks
4, Metro
5, Local Area Networks (LANs)
6, Data processing networks
7, Test equipment
8, Premise installations
9, Wide Area Networks (WANs)
Follows are for your choice:
>NEOFIBO能提供什么?
我们提供全系列的高质量和全面的光纤产品，包括跳线生产机，抛光夹具，如Seikoh Giken, Senko, Domaille或定制的;采购产品抛光消耗品，工具，清洁，工具包，测试设备，拼接项目。我们承诺为您提供有吸引力的价格，优良的质量和快速交货!
>送货费是多少?
所列价格都是深圳离岸价。您指定的快递员可以接受。否则，我们将使用联邦快递、DHL、UPS或任何其他货运代理，并收取相应的费用。
>这批货怎么发货?
对于普通库存项目，将在付款确认后的1-2个工作日内发货。然而，对于缺货物品，预计交货期为3-10个工作日。
>我怎样订购这些货物?
NEOIFBO很高兴为我们宝贵的客户提供三个订购渠道，即:，网上订购，传真订购表格，并通过邮件发出正式的采购订单。
>NEOFIBO产品的保修期如何?
所有产品均由NEOFIBO保证(消耗品，正常损耗和磨损除外)，保质期为自购买之日起一年内。任何在材料或工艺上有缺陷并如NEOFIBO指定的那样退回给NEOFIBO的部件，运费已预付，由NEOFIBO选择修理或更换，作为独家补救措施。
